Adjustable ESD Board Racks for Anti-Static Handling 3W-9805401\402\402A\403
Overview:
Product Introduction
Anti-static racks are storage solutions designed to reduce the buildup and discharge of static electricity during handling and storage. They are widely used in electronics, semiconductor, medical, and other static-sensitive industries. By helping protect stored items from electrostatic damage, they also improve workplace safety, organization, and operational efficiency. In many facilities, they are also referred to as tray racks, anti-static tray racks, or anti-static turnover racks.
ESD board racks are especially useful where sensitive components need secure temporary storage, transfer, and classification. Their practical design helps support cleaner workflows and more reliable material management in demanding production environments.
Application Scenarios
- Electronics manufacturing: Ideal for temporary storage and transfer of SMT components such as chips, LEDs, capacitors, and resistors, helping reduce the risk of static damage.
- Laboratories: Suitable for dust-free and anti-static storage of precision instruments, optical lenses, and medical consumables.
- Warehousing and logistics: Helps separate static-sensitive products by zone for circulation and handling, improving workshop organization and 6S management standards.
Technical Specification
| Product name | ESD Rack | ||||
| Product model | 3W-9805401 | 3W-9805402 | 3W-9805402A | 3W-9805403 | |
 |
 |
 |
 |
||
| Specification parameters | ●External dimensions: | 470*190*545mm | (50-400)*185*350mm | (50-400)*355*350mm | 436*1 60*32mm |
| ●Groove depth: | 3mm | 5mm | 5mm | 8mm | |
| ●Groove width: | 5mm | 3.6mm | 3.6mm | 3mm | |
| ●Pitch: | 10mm | 10mm | 10mm | 16mm | |
| ●Number of slots: | 49 | 32 | 32 | 25 | |
| ●Weight: | 4.24kg | 1.72kg | 3.36kg | 0.39kg | |
| Product description | ◆Adjustment range: 2* (10-190) mm | ◆Aluminum strip length can be customized according to customer needs | |||
| ◆Static index: 10e4-10e8Ω | |||||
| Temperature resistance options | □120°C □150°C | ||||
| Color customization | □  □  □  □other |
||||
| Optional accessories | □Side panel | ||||
| □Anti-static label | |||||
*Temperature resistance refers to the maximum temperature that the collection rack can withstand the PCB board
World-Class ESD Manufacturing Capacity
When you source from Sanwei, you are partnering directly with an industry-leading OEM/ODM manufacturer. We operate a state-of-the-art 70,000+ m² integrated production facility in Yueqing Central Industrial Park, Zhejiang, managing every single process from proprietary material formulation to final high-precision product molding.
Integrated Scale
70,000+ m² advanced plant base equipped with heavy-duty precision injection molding machines to handle bulk wholesale orders with stable lead times.
Full-Chain Control
Complete in-house control spanning proprietary anti-static material R&D, structural mold engineering, automated manufacturing, and swift global logistics delivery.
Rigorous Inspection
Strict raw material testing combined with multi-point surface resistivity metering on the production line ensures 100% compliance with international ESD standard guidelines.
Anti-Static Products and Solutions
Delivering comprehensive electrostatic protection across your entire manufacturing and operational lifecycle.
SMT Equipment
Anti-static collection boxes and racks for automated lines.
Storage & Logistics
Turnover carts, shelves, boxes, trays, and component containers.
Workstation & PPE
Anti-static chairs, mats, wrist straps, and personal protection.
Custom Development
Custom mold development and special anti-static materials.
OUR OEM/ODM ADVANTAGES
Advanced R&D & Material Innovation
In-house developed anti-static materials with national invention patents and heat resistance up to 200℃. We do not just mold — we formulate compounds.
Full-Scale Production Capacity
30,000㎡ plant with complete injection molding, granulation and supporting processing systems for stable and efficient supply.
Full-Process Customization
Material resistivity, color, size, logo, packaging and certifications — customizable to meet IEC61340-5-1, ANSI/ESD S20.20 or military standards.
Certified Quality & Global Compliance
“Sanwei successfully developed custom high-temperature resistant clean natural color trays for our semiconductor assembly line, replacing imported products, ensuring excellent ESD safety, and meeting the high cleanliness requirements of the workshop.”
TRUSTED BY GLOBAL FORTUNE 500 INDUSTRY LEADERS
Our proprietary ESD solutions are deployed in elite production facilities worldwide, including: Intel, Motorola, Siemens, IBM, Panasonic, Nokia, and Dell.
Looking for Custom Sizes or Bulk Wholesale Pricing?
Backed by our robust in-house R&D team, Sanwei provides complete OEM/ODM options tailored to your specific SMT production lines or warehouse layout. Contact our specialists today for custom molds, color coding, or integrated 5S storage consulting.
Frequently Asked Questions (FAQ)
What is an ESD container?
An ESD container is a storage or transport container designed to reduce static electricity buildup and protect sensitive electronic parts from electrostatic discharge. It is commonly used for components, assemblies, and tools that need safe handling in electronics manufacturing and logistics.
What is the best anti-static material?
The best anti-static material depends on the application. For durable industrial use, conductive plastics, anti-static polypropylene, and metal structures with proper surface treatment are common choices. For packaging and temporary protection, anti-static foam, bags, and trays are often used.
What is anti-static equipment?
Anti-static equipment refers to tools and devices used to control static electricity in the workplace. This can include anti-static racks, wrist straps, mats, ionizers, containers, and grounding systems that help protect sensitive products and improve safety.
What are the common ESD protection devices?
Common ESD protection devices include anti-static trays, racks, bins, bags, wrist straps, heel straps, mats, ionizers, and grounding accessories. These devices are used together to reduce the risk of electrostatic damage during storage, transport, assembly, and inspection.
What industries use ESD containers most often?
ESD containers are widely used in electronics manufacturing, semiconductor production, laboratories, medical supply handling, and precision instrument storage.
How do anti-static racks help in production management?
Anti-static racks help keep sensitive items organized, reduce handling damage, and support cleaner workflow separation. They also improve efficiency in storage, transfer, and workshop management.
Are ESD containers reusable?
Yes, many ESD containers are designed for repeated use. Durable materials such as anti-static plastics or metal structures make them suitable for long-term industrial applications.
